5-** Digital In / Out
Par.
No. #
Parameter description Default value 4-set-up Change dur-
ing opera-
tion
Conver-
sion index
Type
5-0* Digital I/O mode
5-01 Terminal 27 Mode [0] Input All set-ups TRUE - Uint8
5-02 Terminal 29 Mode [0] Input All set-ups TRUE - Uint8
5-1* Digital Inputs
5-10 Terminal 18 Digital Input [8] Start All set-ups TRUE - Uint8
5-11 Terminal 19 Digital Input
[0] No opera-
tion All set-ups TRUE - Uint8
5-12 Terminal 27 Digital Input
[2] Coast In-
verse
All set-ups TRUE - Uint8
5-13 Terminal 29 Digital Input [14] Jog All set-ups TRUE - Uint8
5-14 Terminal 32 Digital Input
[0] No opera-
tion
All set-ups TRUE - Uint8
5-15 Terminal 33 Digital Input
[0] No opera-
tion All set-ups TRUE - Uint8
5-16 Terminal X30/2 Digital Input
[0] No opera-
tion
All set-ups TRUE - Uint8
5-17 Terminal X30/3 Digital Input
[0] No opera-
tion All set-ups TRUE - Uint8
5-18 Terminal X30/4 Digital Input
[0] No opera-
tion
All set-ups TRUE - Uint8
5-3* Digital Outputs
5-30 Terminal 27 Digital Output
[0] No opera-
tion
All set-ups TRUE - Uint8
5-31 Terminal 29 Digital Output
[0] No opera-
tion All set-ups TRUE - Uint8
5-32
Term X30/6 Digi Out (MCB
101)
[0] No opera-
tion
All set-ups TRUE - Uint8
5-33
Term X30/7 Digi Out (MCB
101)
[0] No opera-
tion All set-ups TRUE - Uint8
5-4* Relays
5-40 Function Relay null All set-ups TRUE - Uint8
5-41 On Delay, Relay 0.01 s All set-ups TRUE -2 Uint16
5-42 Off Delay, Relay 0.01 s All set-ups TRUE -2 Uint16
5-5* Pulse Input
5-50 Term. 29 Low Frequency 100 Hz All set-ups TRUE 0 Uint32
5-51 Term. 29 High Frequency 100 Hz All set-ups TRUE 0 Uint32
5-52
Term. 29 Low Ref./Feedb.
Value 0.000 N/A All set-ups TRUE -3 Int32
5-53
Term. 29 High Ref./Feedb.
Value
100.000 N/A All set-ups TRUE -3 Int32
5-54
Pulse Filter Time Constant
#29 100 ms All set-ups FALSE -3 Uint16
5-55 Term. 33 Low Frequency 100 Hz All set-ups TRUE 0 Uint32
5-56 Term. 33 High Frequency 100 Hz All set-ups TRUE 0 Uint32
5-57
Term. 33 Low Ref./Feedb.
Value
0.000 N/A All set-ups TRUE -3 Int32
5-58
Term. 33 High Ref./Feedb.
Value 100.000 N/A All set-ups TRUE -3 Int32
5-59
Pulse Filter Time Constant
#33
100 ms All set-ups FALSE -3 Uint16
