Trane TR200 - Page 144

Par.
No. #
Parameter description Default value 4-set-up Change dur-
ing opera-
tion
Conver-
sion index
Type
5-6* Pulse Output
5-60
Terminal 27 Pulse Output
Variable
[0] No opera-
tion All set-ups TRUE - Uint8
5-62 Pulse Output Max Freq #27 5000 Hz All set-ups TRUE 0 Uint32
5-63
Terminal 29 Pulse Output
Variable
[0] No opera-
tion All set-ups TRUE - Uint8
5-65 Pulse Output Max Freq #29 5000 Hz All set-ups TRUE 0 Uint32
5-66
Terminal X30/6 Pulse Output
Variable
[0] No opera-
tion All set-ups TRUE - Uint8
5-68
Pulse Output Max Freq
#X30/6
5000 Hz All set-ups TRUE 0 Uint32
5-9* Bus Controlled
5-90 Digital & Relay Bus Control 0 N/A All set-ups TRUE 0 Uint32
5-93 Pulse Out #27 Bus Control 0.00 % All set-ups TRUE -2 N2
5-94
Pulse Out #27 Timeout Pre-
set
0.00 % 1 set-up TRUE -2 Uint16
5-95 Pulse Out #29 Bus Control 0.00 % All set-ups TRUE -2 N2
5-96
Pulse Out #29 Timeout Pre-
set
0.00 % 1 set-up TRUE -2 Uint16
5-97
Pulse Out #X30/6 Bus Con-
trol 0.00 % All set-ups TRUE -2 N2
5-98
Pulse Out #X30/6 Timeout
Preset
0.00 % 1 set-up TRUE -2 Uint16
How to program the Frequency Converter
BAS-SVX19C-EN 6-73
