Trane TR200 - 2-** Brakes

2-** Brakes
Par.
No. #
Parameter description Default value 4-set-up Change dur-
ing operation
Conver-
sion index
Type
2-0* DC-Brake
2-00 DC Hold/Preheat Current 0 % All set-ups TRUE 0 Uint8
2-01 DC Brake Current 0 % All set-ups TRUE 0 Uint16
2-02 DC Braking Time 10.0 s All set-ups TRUE -1 Uint16
2-03 DC Brake Cut In Speed [RPM]
ExpressionLi-
mit
All set-ups TRUE 67 Uint16
2-04 DC Brake Cut In Speed [Hz] 10Hz All set-ups TRUE -1 Uint16
2-1* Brake Energy Funct.
2-10 Brake Function [0] Off All set-ups TRUE - Uint8
2-11 Brake Resistor (ohm)
ExpressionLi-
mit
All set-ups TRUE 0 Uint16
2-12 Brake Power Limit (kW)
ExpressionLi-
mit All set-ups TRUE 0 Uint32
2-13 Brake Power Monitoring [0] Off All set-ups TRUE - Uint8
2-15 Brake Check [0] Off All set-ups TRUE - Uint8
2-16 AC brake Max. Current
ExpressionLi-
mit
All set-ups TRUE -1 Uint32
2-17 Over-voltage Control [2] Enabled All set-ups TRUE - Uint8
How to program the Frequency Converter
6-68 BAS-SVX19C-EN
