8-** Communication and Options
Par.
No. #
Parameter description Default value 4-set-up Change dur-
ing opera-
tion
Conver-
sion index
Type
8-0* General Settings
8-01 Control Site null All set-ups TRUE - Uint8
8-02 Control Source null All set-ups TRUE - Uint8
8-03 Control Timeout Time
ExpressionLi-
mit 1 set-up TRUE -1 Uint32
8-04 Control Timeout Function [0] Off 1 set-up TRUE - Uint8
8-05 End-of-Timeout Function
[1] Resume set-
up 1 set-up TRUE - Uint8
8-06 Reset Control Timeout [0] Do not reset All set-ups TRUE - Uint8
8-07 Diagnosis Trigger [0] Disable 2 set-ups TRUE - Uint8
8-09 Communication Charset [0] ISO 8859-1 2 set-ups TRUE - Uint8
8-1* Control Settings
8-10 Control Profile [0] Drive profile 2 set-ups FALSE - Uint8
8-13
Configurable Status Word
STW
[1] Profile De-
fault All set-ups TRUE - Uint8
8-3* Drive Port Settings
8-30 Protocol null 1 set-up TRUE - Uint8
8-31 Address
ExpressionLi-
mit
1 set-up TRUE 0 Uint8
8-32 Baud Rate null 1 set-up TRUE - Uint8
8-33 Parity / Stop Bits null 1 set-up TRUE - Uint8
8-35 Minimum Response Delay
ExpressionLi-
mit 1 set-up TRUE -3 Uint16
8-36 Maximum Response Delay
ExpressionLi-
mit
1 set-up TRUE -3 Uint16
8-37 Maximum Inter-Char Delay
ExpressionLi-
mit 1 set-up TRUE -5 Uint16
8-4* Drive MC protocol set
8-40 Telegram Selection
[1] Standard
telegram 1 2 set-ups TRUE - Uint8
8-5* Digital/Bus
8-50 Coasting Select [3] Logic OR All set-ups TRUE - Uint8
8-52 DC Brake Select [3] Logic OR All set-ups TRUE - Uint8
8-53 Start Select [3] Logic OR All set-ups TRUE - Uint8
8-54 Reversing Select null All set-ups TRUE - Uint8
8-55 Set-up Select [3] Logic OR All set-ups TRUE - Uint8
8-56 Preset Reference Select [3] Logic OR All set-ups TRUE - Uint8
8-7* BACnet
8-70 BACnet Device Instance 1025 N/A 1 set-up TRUE 0 Uint32
8-72 MS/TP Max Masters 127 N/A 1 set-up TRUE 0 Uint8
8-73 MS/TP Max Info Frames 1 N/A 1 set-up TRUE 0 Uint16
8-74 "I-Am" Service
[0] Send at pow-
er-up 1 set-up TRUE - Uint8
8-75 Initialization Password
ExpressionLi-
mit
1 set-up TRUE 0 VisStr[25]
8-8* Drive Port Diagnostics
8-80 Bus Message Count 0 N/A All set-ups TRUE 0 Uint32
8-81 Bus Error Count 0 N/A All set-ups TRUE 0 Uint32
8-82 Slave Messages Rcvd 0 N/A All set-ups TRUE 0 Uint32
8-83 Slave Error Count 0 N/A All set-ups TRUE 0 Uint32
8-84 Slave Messages Sent 0 N/A All set-ups TRUE 0 Uint32
8-85 Slave Timeout Errors 0 N/A All set-ups TRUE 0 Uint32
8-88 Reset Drive port Diagnostics [0] Do not reset All set-ups TRUE - Uint8
8-89 Diagnostics Count 0 N/A 1 set-up TRUE 0 Int32
