Trane TR200 - Motor Power (Kw; HP); Motor Voltage; Motor Frequency; Motor Current

1-20 Motor Power [kW]
Range: Function:
Applica-
tion de-
pend-
ent*
[Application dependant] Enter the nominal motor power in kW according to the motor nameplate
data. The default value corresponds to the nominal rated output of the
unit.
This parameter cannot be adjusted while the motor is running. Depend-
ing on the choices made in par. 0-03
Regional Settings, either
par. 1-20
Motor Power [kW] or par. 1-21 Motor Power [HP] is made in-
visible.
1-21 Motor Power [HP]
Range: Function:
Applica-
tion de-
pend-
ent*
[Application dependant] Enter the nominal motor power in HP according to the motor nameplate
data. The default value corresponds to the nominal rated output of the
unit.
This parameter cannot be adjusted while the motor is running.
Depending on the choices made in par. 0-03
Regional Settings, either
par. 1-20
Motor Power [kW] or par. 1-21 Motor Power [HP] is made in-
visible.
1-22 Motor Voltage
Range: Function:
Applica-
tion de-
pend-
ent*
[Application dependant] Enter the nominal motor voltage according to the motor nameplate data.
The default value corresponds to the nominal rated output of the unit.
This parameter cannot be adjusted while the motor is running.
1-23 Motor Frequency
Range: Function:
Applica-
tion de-
pend-
ent*
[20 - 1000 Hz] Select the motor frequency value from the motor nameplate data.For 87
Hz operation with 230/400 V motors, set the nameplate data for 230 V/50
Hz. Adapt par. 4-13
Motor Speed High Limit [RPM] and par. 3-03 Maxi-
mum Reference to the 87 Hz application.
This parameter cannot be adjusted while the motor is running.
1-24 Motor Current
Range: Function:
Applica-
tion de-
pend-
ent*
[Application dependant] Enter the nominal motor current value from the motor nameplate data.
This data is used for calculating motor torque, motor thermal protection
etc.
This parameter cannot be adjusted while the motor is running.
How to program the Frequency Converter
BAS-SVX19C-EN 6-5
