Trane TR200 - Dedicated Factory Settings

Dedicated factory settings
Frequency converters delivered as part of a Trane equipment can have dedicated factory settings. Upon factory
reset of the frequency converter these parameter settings will be used as default. See below for details on the
specific equipment settings.
Trane IntelliPak
™
, IntelliPak
™
II, and Voyager III
™
Par. No. # Parameter description Trane default value
0-01 Language [22] English US
0-03 Regional Unit Settings [1] North America
0-20 Display Line 1.1 Small [1662] Analog Input 53
0-22 Display Line 1.3 Small [1611] Power [hp]
0-40 Hand Start Button [0] Disabled
1-03 Torque Characteristics [1] Variable
1-21 Motor Power [HP] Reference Motor Nameplate HP
1-22 Motor Voltage Reference Motor Nameplate Voltage
1-24 Motor Current Reference Motor Nameplate FLA
1-25 Motor Nominal Speed Reference Motor Nameplate Rated Speed
1-73 Flying Start [1] Enabled
2-00 DC Hold/Preheat Current 0%
2-01 DC Brake Current 0%
2-04 DC Brake Cut-in Speed [Hz] 10Hz
3-41 Ramp 1 Ramp-up Time 30 Sec.
3-42 Ramp-down Time 30 Sec.
4-12 Motor Speed Low Limit [Hz] 22 Hz IntelliPak
35 Hz Voyager lll
4-18 Current Limit 100%
5-12 Terminal 27, Digital Input [2] Coast Inverse
6-14 Terminal 53 Low Ref./Feedb. Value 22 Hz IntelliPak
35 Hz Voyager lll
14-01 Switching Frequency 208/203V, 30 Hp and below 8kHz, above 5 kHz
460/575V, 60 Hp and below 8 kHz, above 5 kHz
14-12 Function at Mains Imbalance [3] Derate
14-20 Reset Mode [3] Automatic reset x 3
14-60 Function at Overtemperature [1] Derate
14-61 Function at Invertor Overload [1] Derate
How to program the Frequency Converter
BAS-SVX19C-EN 6-95
