Par.
No. #
Parameter description Default value 4-set-up Change
during op-
eration
Conver-
sion in-
dex
Type
36-5* Output X49/9
36-50 Terminal X49/9 analog Output
[0] No opera-
tion All set-ups TRUE - Uint8
36-51 Terminal X49/9 Digital Output
[0] No opera-
tion
All set-ups TRUE - Uint8
36-52 Terminal X49/9 Min. Scale 0.00 % All set-ups TRUE -2 Int16
36-53 Terminal X49/9 Max. Scale 100.00 % All set-ups TRUE -2 Int16
36-54 Terminal X49/9 Bus Control 0.00 % All set-ups TRUE -2 N2
36-55 Terminal X49/9 Timeout Preset 0.00 % 1 set-up TRUE -2 Uint16
36-6* Output X49/11
36-60 Terminal X49/11 analog Output
[0] No opera-
tion
All set-ups TRUE - Uint8
36-61 Terminal X49/11 Digital Output
[0] No opera-
tion All set-ups TRUE - Uint8
36-62 Terminal X49/11 Min. Scale 0.00 % All set-ups TRUE -2 Int16
36-63 Terminal X49/11 Max. Scale 100.00 % All set-ups TRUE -2 Int16
36-64 Terminal X49/11 Bus Control 0.00 % All set-ups TRUE -2 N2
36-65 Terminal X49/11 Timeout Preset 0.00 % 1 set-up TRUE -2 Uint16
