Trane TR200 - 23-** Time Based Funtions

23-** Time Based Funtions
Par.
No. #
Parameter description Default value 4-set-up Change
during op-
eration
Conver-
sion index
Type
23-0* Timed Actions
23-00 ON Time
ExpressionLi-
mit 2 set-ups TRUE 0
TimeOf-
DayWo-
Date
23-01 ON Action [0] Disabled 2 set-ups TRUE - Uint8
23-02 OFF Time
ExpressionLi-
mit 2 set-ups TRUE 0
TimeOf-
DayWo-
Date
23-03 OFF Action [1] No action 2 set-ups TRUE - Uint8
23-04 Occurrence [0] All days 2 set-ups TRUE - Uint8
23-0* Timed Actions Settings
23-08 Timed Actions Mode
[0] Timed Ac-
tions Auto 2 set-ups TRUE - Uint8
23-09
Timed Actions Reactiva-
tion
[1] Enabled 2 set-ups TRUE - Uint8
23-1* Maintenance
23-10 Maintenance Item
[1] Motor bear-
ings
1 set-up TRUE - Uint8
23-11 Maintenance Action [1] Lubricate 1 set-up TRUE - Uint8
23-12 Maintenance Time Base [0] Disabled 1 set-up TRUE - Uint8
23-13 Maintenance Time Interval 1 h 1 set-up TRUE 74 Uint32
23-14
Maintenance Date and
Time
ExpressionLi-
mit
1 set-up TRUE 0 TimeOfDay
23-1* Maintenance Reset
23-15 Reset Maintenance Word
[0] Do not re-
set
All set-ups TRUE - Uint8
23-16 Maintenance Text 0 N/A 1 set-up TRUE 0 VisStr[20]
23-5* Energy Log
23-50 Energy Log Resolution
[5] Last 24
Hours 2 set-ups TRUE - Uint8
23-51 Period Start
ExpressionLi-
mit
2 set-ups TRUE 0 TimeOfDay
23-53 Energy Log 0 N/A All set-ups TRUE 0 Uint32
23-54 Reset Energy Log
[0] Do not re-
set
All set-ups TRUE - Uint8
23-6* Trending
23-60 Trend Variable [0] Power [kW] 2 set-ups TRUE - Uint8
23-61 Continuous Bin Data 0 N/A All set-ups TRUE 0 Uint32
23-62 Timed Bin Data 0 N/A All set-ups TRUE 0 Uint32
23-63 Timed Period Start
ExpressionLi-
mit 2 set-ups TRUE 0 TimeOfDay
23-64 Timed Period Stop
ExpressionLi-
mit
2 set-ups TRUE 0 TimeOfDay
23-65 Minimum Bin Value
ExpressionLi-
mit 2 set-ups TRUE 0 Uint8
23-66 Reset Continuous Bin Data
[0] Do not re-
set
All set-ups TRUE - Uint8
23-67 Reset Timed Bin Data
[0] Do not re-
set All set-ups TRUE - Uint8
23-8* Payback Counter
23-80 Power Reference Factor 100 % 2 set-ups TRUE 0 Uint8
23-81 Energy Cost 1.00 N/A 2 set-ups TRUE -2 Uint32
23-82 Investment 0 N/A 2 set-ups TRUE 0 Uint32
23-83 Energy Savings 0 kWh All set-ups TRUE 75 Int32
23-84 Cost Savings 0 N/A All set-ups TRUE 0 Int32
How to program the Frequency Converter
BAS-SVX19C-EN 6-91
