Function Set-ups parameters
The Function Set-ups parameters are grouped in the following way:
Q3-1 General Settings
Q3-10 Adv. Motor Set-
tings
Q3-11 Analog Output Q3-12 Clock Settings Q3-13 Display Settings
Par. 1-90
Motor Thermal
Protection
Par. 6-50
Terminal 42
Output
Par. 0-70
Date and Time Par. 0-20 Display Line 1.1
Small
Par. 1-93
Thermistor
Source
Par. 6-51
Terminal 42
Output Min Scale
Par. 0-71
Date Format Par. 0-21 Display Line 1.2
Small
Par. 1-29
Automatic Mo-
tor Adaptation (AMA)
Par. 6-52
Terminal 42
Output Max Scale
Par. 0-72
Time Format Par. 0-22 Display Line 1.3
Small
Par. 14-01
Switching Fre-
quency
Par. 0-74
DST/Summer-
time
Par. 0-23
Display Line 2
Large
Par. 4-53
Warning Speed
High
Par. 0-76
DST/Summer-
time Start
Par. 0-24
Display Line 3
Large
Par. 0-77
DST/Summer-
time End
Par. 0-37
Display Text 1
Par. 0-38
Display Text 2
Par. 0-39
Display Text 3
Q3-2 Open Loop Settings
Q3-20 Digital Reference Q3-21 Analog Reference
Par. 3-02
Minimum Reference Par. 3-02 Minimum Reference
Par. 3-03
Maximum Reference Par. 3-03 Maximum Reference
Par. 3-10
Preset Reference Par. 6-10 Terminal 53 Low Voltage
Par. 5-13
Terminal 29 Digital Input Par. 6-11 Terminal 53 High Voltage
Par. 5-14
Terminal 32 Digital Input Par. 6-12 Terminal 53 Low Current
Par. 5-15
Terminal 33 Digital Input Par. 6-13 Terminal 53 High Current
Par. 6-14
Terminal 53 Low Ref./Feedb. Value
Par. 6-15
Terminal 53 High Ref./Feedb. Value
How to program the Frequency Converter
