Trane TR200 - Mechanical Dimensions

Mechanical Dimensions
Frame size (kW): A2 A3 A4 A5 B1 B2 B3 B4 C1 C2 C3 C4
200-240 V 380-480 V 525-600 V
1.1-2.2
1.1-4.0
3.0-3.7 5.5-7.5 1.1-7.5
1.1-2.2 1.1-4.0
1.1-3.7 1.1-7.5 1.1-7.5
5.5-11 11-18.5 11-18.5
15 22-30 22-30
5.5-11 11-18.5 11-18.5
15-18.5 22-37 22-37
18.5-30 37-55 37-55
37-45 75-90 75-90
22-30 45-55 45-55
37-45 75-90 75-90
IP NEMA
20
Chassis
21 Type 1
20 Chassis
21 Type 1
55/66 55/66
Type 12
21/ 55/66 Type 1/12
21/ 55/66 Type 1/12
20 Chassis
20 Chassis
21/ 55/66 Type 1/12
21/ 55/66 Type 1/12
20 Chassis
20 Chassis
Height (mm)
Enclosure A** 246 372 246 372 390 420 480 650 350 460 680 770 490 600
..with de-coupling plate A2 374 - 374 - - - - - 419 595 - - 630 800
Back plate A1 268 375 268 375 390 420 480 650 399 520 680 770 550 660
Distance between mount. holes
a 257 350 257 350 401 402 454 624 380 495 648 739 521 631
Width (mm) Enclosure B 90 90 130 130 200 242 242 242 165 231 308 370 308 370 With one C option B 130 130 170 170 242 242 242 205 231 308 370 308 370
Back plate B 90 90 130 130 200 242 242 242 165 231 308 370 308 370
Distance between mount. holes
b 70 70 110 110 171 215 210 210 140 200 272 334 270 330
Depth (mm)
Without option A/B C 205 205 205 205 175 200 260 260 248 242 310 335 333 333
With option A/B C* 220 220 220 220 175 200 260 260 262 242 310 335 333 333
Screw holes (mm) c 8.0 8.0 8.0 8.0 8.2 8.2 12 12 8 - 12 12 - - Diameter ø d 11 11 11 11 12 12 19 19 12 - 19 19 - -
Diameter ø e 5.5 5.5 5.5 5.5 6.5 6.5 9 9 6.8 8.5 9.0 9.0 8.5 8.5
f 9 9 9 9 6 9 9 9 7.9 15 9.8 9.8 17 17
Max weight (kg)
4.95.36.67.09.7 14 23 27 1223.5 45 65 35 50
* Depth of enclosure will vary with different options installed. ** The free space requirements are above and below the bare enclosure height measurement A. See section
Mechanical Mounting
for further information.
Mechanical Dimensions
Mechanical Installation
BAS-SVX19C-EN 3-3
