Trane M-Series and T-Series Climate Changer
™
, Performance Climate Changer
™
- Indoor & Outdoor
Par. No. # Parameter description Trane default value
0-03 Regional Unit Settings [1] North America
1-21 Motor Power [HP] Reference Motor Nameplate HP
1-22 Motor Voltage Reference Motor Nameplate Voltage
1-24 Motor Current Reference Motor Nameplate FLA
1-25 Motor Nominal Speed Reference Motor Nameplate Rated Speed
1-73 Flying Start [Enabled]
3-03 Maximum Reference 60 Hz or (for direct drive) Set for Application
3-41 Ramp 1 Ramp-up Time 30 Sec.
3-42 Ramp 1 Ramp-down Time 30 Sec.
4-12 Motor Speed Low Limit [Hz] 20 Hz
4-14 Motor Speed High Limit [Hz] 60 Hz or (for direct drive) Set for Application
5-12 Terminal 27 Digital Input [2] Coast Inverse
6-14 Terminal 53 Low Ref./Feedb. Value 20 Hz
6-15 Terminal 53 High Ref./Feedb. Value 60 Hz or (for direct drive) Set for Application
14-01 Switching Frequency 208/230V, 30 Hp and below 8kHz, above 5 kHz
460/575V, 60 Hp and below 8 kHz, above 5 kHz
Trane Commercial Self Contained and Packaged Climate Changer
TM
Par. No. # Parameter description Trane default value
0-01 Language [22] English US
0-03 Regional Settings [1] North America
0-22 Display Line 1.3 Small [1611] Power [HP]
1-21 Motor Power [HP] Reference Motor Nameplate HP
1-22 Motor Voltage Reference Motor Nameplate Voltage
1-24 Motor Current Reference Motor Nameplate FLA
1-25 Motor Nominal Speed Reference Motor Nameplate Rated Speed
1-73 Flying Start [1] Enabled
3-41 Ramp 1 Ramp-up Time 30 Sec.
3-42 Ramp 1 Ramp-down Time 30 Sec.
4-12 Motor Speed Low Limit [Hz] 22 Hz
5-12 Terminal 27, Digital Input [2] Coast Inverse, Commercial Self Contained
[0] No operation, Packaged Climate Changer
6-14 Terminal 53 Low Ref. / Feedb. Value 22 Hz
14-01 Switching Frequency 8 kHz
14-12 Function at Mains Imbalance [3] Derate
14-21 Automatic Restart Time 3 Sec.
14-60 Function at Overtemperature [1] Derate
How to program the Frequency Converter
6-96 BAS-SVX19C-EN
