D300529 0115 - BL67 I/O modules
10-13
BL67-4AI4AO-VI, voltage/current
 12-bit-representation (left-justified)
NOTE
If the measurement value representation is parameterized as "12 bit left-justified" the diag-
nostic data will be transferred with the process data bits 0 to 3 of the respective channel.
-10 … 10 V bipolar Diagnostics dec. hex.
voltag
e value U
M
= (dec. value/16 × 4,885 × 10
-3
) V
> 10.1000 V
at ↑ DIA Measured value out
of range
ON
2047 × 16 7FFF
≤ 10.0500 V
at ↓ DIA Measured value out
of range
OFF
2047 × 16 7FFF
10.0000 V
nominal range
2047 × 16 7FFF
9.9951 V 2046 × 16 7FE×
………
5.00244 V 1024 × 16 400×
………
0.00488 V 1 × 16 001×
0.000000 V 0 000×
-0.000488 V -1 × 16 FFF×
………
-5.0000 V -1024 × 16 C00×
………
-9.99511 V -2047 × 16 801×
≤ -10.0000 V -2048 × 16 800×
≥ -10,0500 V
at ↑ DIA Measured value out
of range
OFF
-2048 × 16 800×
< -10,1000 V
at ↓ DIA Measured value out
of range
ON
-2048 × 16 800×
0 … 10 V unipolar Diagnostics dec. hex.
voltage value U
M
= (dec. value/16 × 2,442 × 10
-3
) V
> 10.1000 V
at ↑ DIA Measured value out
of range ON
4095 × 16 FFF×
≤ 10.0500 V
at ↓ DIA Measured value out
of range
OFF
4095 × 16 FFF×
10.0000 V
nominal range
4095 × 16 FFF×
9.9976 V 4094 × 16 FFE×
………
5.0012 V 2048 × 16 800×
………
0.00244 V 1 × 16 001×
≤ 0.0000 V 0 000×
≥ -0,0500 V
at ↑ DIA Measured value out
of range
OFF
0000×
< -0,1000 V
at ↓ DIA Measured value out
of range
ON
0000×
