UTT Technologies VPN Menu
http://www.uttglobal.com Page 183
Connection Type Bidirectional
Gateway IP/Domain Name (Remote) 200.200.202.123
Subnet IP (Remote) 192.168.123.1
Subnet Mask (Remote) 255.255.255.0
Bind to (Local) WAN1
Subnet IP (Local) 192.168.16.1
Subnet Mask (Local) 255.255.255.0
Preshared Key testing
P2 Encrypt/Auth Algorithms 1 esp-aes256-md5
3) Viewing the IPSec tunnel status
After you have configured IPSec parameters on both Devices, the IPSec tunnel
establishment can be triggered manually.
On the Device, you can go to the
VPN > IPSec > IPSec List page to view the
configuration of the IPSec tunnel, including the
SA Status, Remote Gateway, Remote
Subnet, Bind to and Local Subnet. After the IPSec tunnel has been established, you
can see that the
SA Status displays Established.
Figure 13-18 IPSec List – Bidirectional
