INSTRUMENTSANDCONTROLS101

ECCAirDistribution

W8003067

1TemperatureSensor

CAUTION

Thetemperaturesensorshowninthe

illustration,detectsthetemperaturein

thecab.DONOTcoverthesensor,

andDONOTplacewarmobjects,like

coffeemakersorrefrigerators,closeto

thesensor.

Alwaysallowthedashboardvents(seearrowsinillustration)toremainopen.

Irrespectiveofhowtheairdistributionisset,asmallamountofairwillalwayscome

fromthedashboardventstoensurethetemperatureinthecabiscorrect.

Note:FloorMode:Unheatedairisleakedtothepanelventtobalancetheheatrising

fromtheoor.
