78INSTRUMENTSANDCONTROLS

15.EngineBrakeModeSelect(ISX)

Formoreinformationabouttheenginebrake,see“V olvoEngineBrake(I-VEB)”,

page272.

W3002303

I-ShiftHillStartAssist

Formoreinformationonthisfeature,pleaserefertotheI-ShiftTransmissionManual

suppliedwithyourvehicle.

W3028392

OptionalSwitch
