INSTRUMENTSANDCONTROLS85

29.TrailerHandBrakeControl

Thetrailerhandbrakecontrolengagesthetrailerbrakes.Forinformationaboutthe

trailerhandbrakecontrol,referto“TrailerBrakeHandControl”,page288.

30.PassengerWindowControlSwitchorOptionalSwitch

Thetrailerhandbrakecontrolengagesthetrailerbrakes.Forinformationaboutthe

trailerhandbrakecontrol,referto“TrailerBrakeHandControl”,page288.

31.Water-In-Fuel(PurgeSwitch)(Optional)

Thewater-in-fueldrainswitchisanon-lockingswitchusedtodrainthefuelwater

separatoronV olvoengines.

W3005378

Water-In-FuelDrainSwitch

Asymboldisplayedintheinstrumentpanelindicateswhenitisrecommendedto

drainthewaterseparator.

W3005378

Water-In-FuelSymbol

Stopattherstopportunityanddrainthewaterseparator.Ifthewarningsymbol

frequentlyrecommendsthatthewaterseparatorbedrained,thenthereisaproblem

withthefuelquality.Drainthefueltankandrellwithfuelofthecorrectquality.
