OPERATION271

Note:Thecruisecontrolcannotbeengagedatspeedsbelowapproximately30km/h

(18mph).

Disengaging

Thecruisecontrolisdisengagedifthebrakeisdepressed,orifthecruisecontrol

switchissettoOFF.Iftheignitionkeyisturnedbacktotheaccessoriesposition(I),

thecruisecontrolsystemwillautomaticallybedisengaged.

Ifcongured,thecruisecontrolwillremainengagediftheclutchpedalisdepressed

forshortdurations(toallowshiftingwhileincruisecontrol).However,iftheclutch

pedalisdepressedforanextendedperiod(typicallygreaterthan5seconds),cruise

controlwillbedisengaged.

ResumingVehicleSpeed

Thepreviouslyselectedcruisespeedisretainedinthememory.Whenthecruise

controlswitchispushedtotheRESUMEposition,thevehicleresumesthepreviously

setspeed(providedvehiclespeedexceedsapproximately15km/h[10mph]whenthe

switchispressedandthespeedisnotabovethemaximumprogrammedspeed).
