86INSTRUMENTSANDCONTROLS

DrainingProcedure

Note:Iftheengineisstartedbeforedrainingiscomplete,theprocessisinterrupted.

1Stopthevehicle.

2Applytheparkingbrake.

3Turnofftheengine.

4Placeacontainerunderthewaterseparator.

5Turntheignitionkeycounterclockwisetothe"Radio,Accessories"position.

6IfthevehicleisequippedwithaMidInstrumentCluster,presstheWater-In-Fuel

DrainSwitch.

7IfthevehicleisequippedwithaMidorHighLevelInstrumentCluster,select

"VehicleSetting"/"DrainWaterinFuel"intheDriverInformationDisplaymenu.

PressEnter(↵)torequestdraining.Thefollowingmenuisdisplayed.

W3028406

8Waituntilthewaterhasstoppeddraining.

9Emptythecontainerinaplacewherethecontentswillnotcauseenvironmental

damage.
