6.Inter-AxleDifferentialLock

Theinter-axledifferentiallockeliminatesslippingbetweenaxlestoimprovetraction.

Theswitchhasasafetylatchtopreventaccidentalengagement.

W3028391

Whenthelockisengaged,atell-talelightsupintheinstrumentcluster.

W3006119

Inter-AxleTell-Tale

Adifferentiallockshouldonlybeusedonaslipperysurface,NOTwhendrivingon

goodroadconditions.Ifadifferentiallocktell-taleisactivatedintheinstrument

cluster,DONOTmaketurnsuntilthetell-talehasgoneout.Referto“AXLES”,page

342"AXLES"forinformationonhowtoproperlyengageanddrivewithdifferential

locksengaged.
