438MAINTENANCEANDLUBRICATION

CAUTION

DONOTweldontheengineorengine

components.Weldingontheengine

orcomponentsmountedontheengine

cancauseseriousdamagetotheengine

ECU.

Note:DONOTworkontheelectric

systemwithoutpropertoolsandtraining.

Repairworktotheelectricalsystemmust

bedonebytrainedprofessionals.Your

authorizedV olvoTruckdealerhasthe

righttoolsandtrainedtechnicians.

ChargingSystem

Analternatorwithanintegratedregulatorisusedtosupplypowertothevehicle

electricalsystem.Thechargingsystemvoltageshouldbecheckedperiodicallyto

preventoverchargingorunderchargingthebatteries.

W3005339
