MAINTENANCEANDLUBRICATION415

FRONTBUMPER/LICENSEPLATE

MOUNTING

CAUTION

DONOTcovertheopeninginthefront

bumperwithalicenseplate.Covering

thisholewillrestrictairowtothe

lowerportionoftheradiator.Thiscan

causetheenginetooverheat,whichcan

damagetheengine.

Whenplacingthelicenseplateonthevehicle,makesuretheopeninginthebumperis

notcovered.

W8003518
