238OPERATION

SafetyRestraintVN430,VN630,VN670

Therestrainthaslatchesinoneendandbucklesintheothersoitcanonlybeinstalled

oneway.Connecttherestrainttothebackwallandthebucklesontheoor.Connect

thesidetethersandadjustthestrapstoforma"tent"overthebunk(VN670upper

bunkdoesnothavethe"tenting"feature).

W8003206
