134INSTRUMENTSANDCONTROLS

FreshAirVent

A.Closed

B.Open

C.VerticalAirFlow

D.LateralAirFlow

T0008094

Whenheatingthecab,allventsshouldbeclosed.However,theventsontheouterparts

ofthedashcanbeusedfordefrostingthecabdoorwindows.Whenoperatingtheair

conditioning,allairventsshouldbecompletelyopenandtheairowdirectedupward.

DANGER

DONOTbreathetheengineexhaust

gas.Itcontainscarbonmonoxide,

whichhasnocolororodor.Carbon

monoxideisadangerousgaswhichcan

causeunconsciousnessordeath.
