OPERATION317

UnlockingtheFifthWheel

Alwayscheckouttheentirefthwheelbeforeattemptingtocoupletoatrailer(ASF

fthwheelisshown).

•Ifnotlubricatedproperly,addgreasetothetopofthefthwheelplate.

•Makesurethemountingofthefthwheeltotheframeistightandingood

condition.

•Ifusingaslidingfthwheel,makesuretheslidelockingplungersareinalocked

position.

Thefollowinginstructionsareforpreparingthefthwheelforcouplingtoatrailer:

Rotatethesafetylatchtowardtherearofthefthwheel.

W9000180
