158INSTRUMENTSANDCONTROLS

FrontOverheadStorage

Therearetwocongurationsofoverheadstoragecompartmentsmountedoverthe

windshield:veopeningswithnets,orCBradio,switchpanel,andthreeopenings

withnets.

Thestoragecompartmentshaveamaximumstorageweightlimitofapproximately1.1

kg(2.5lb.)peropeningoratotalof5.6kg(12.5lb.)evenlydistributed.

W8003782

FiveOpeningswithNets
