OPERATION307

T3008841

Ifnecessary,oncetheenginehasstarted,thepreheaterwillreengage(postheating)for

thesamelengthoftimeasthepreheattime.

EnginesWithoutPreheater

Enginesnotequippedwithapreheatermay,dependingoncoolanttemperature,take

longertostart.Ifthisshouldhappen,DONOTreleasetheignitionkeyuntilthe

enginehasstarted(whilestillobservingthe30secondmaximumcrankingtime).

EtherStart

DANGER

DONOTuseetherorothercombustible

startingaidsonanyV olvoengine.

Introductionofetherorsimilarstarting

aidscouldcauseareorexplosion

resultinginseverepropertydamage,

seriouspersonalinjuryordeath.

W0001484
