SAFETYINFORMATION33

DriverSideEntry/Exit

WARNING

Onvehicleswithoutsidefairingsor

cabpanels,alwaysmakesurethatthe

batteryboxcoverissecurelyfastened

beforesteppingup.Failuretofastenthe

covermayleadtoafallandpersonal

injury.

Openthedoor.Placeanyhand-carrieditemsonthecaboor.Grasptherightgrab

handlewithyourrighthandandtheleftgrabhandlewithyourlefthand.Puttheright

footfullyonthebottomstepandpullyourselfuptotheopening.

W8003112

Slidehandsuponthehandles,ifnecessary.Puttheleftfootonthetopstepandstep

up.Stepintothecabwiththerightfootrst.

Toexit,reversetheprocess.Donotattempttoexitthecabwhilecarryinganyitems

inyourhands.
