224OPERATION

CABDOORSANDDOORLOCK

DANGER

Tolessenthechanceofbeingthrown

fromthevehicleincaseofanaccident,

alwayslockthedoorsandwearthe

safetybeltwhiledriving.Failuretodo

socancauseseriouspersonalinjuryor

deathifinvolvedinanaccident.

Thecabdoorscanbeunlockedandlockedwiththesamekeyusedfortheignition

lock.Thereisalsoakeylessremoteentryavailable.Keyscanbemadetotonly

onevehicleorallthevehiclesinaeetofV olvovehicles.Thekeytsinthedoor

lockeitherway.Insertthekeyandturnit1/4turncounterclockwisetounlockor

clockwisetolockthedoor.

W3028591

1Pressoncetounlockdriverside.Presstwicetounlockbothdoors.

2Pressoncetolockdoors.
