396MAINTENANCEANDLUBRICATION

CagingSpringBrakeChambers

DANGER

Alwaysstartbychockingthewheels

topreventthevehiclefromrolling.

Failuretodosocanresultinunexpected

vehiclemovementandseriouspersonal

injuryordeathcanoccur.

DANGER

DONOTattemptinanywayto

disassembleortamperwiththespring

brakechamber.Iftheforcestoredon

thespringissuddenlyreleased,itcan

causeseriouspersonalinjuryordeath.

Theparkingspringbrakechambersmaybereleasedmechanicallyifthereisno

compressedairavailable.

Removetheplasticpluginthefrontendofthechamber.Removethescrewfromthe

holderinthesideofthebrakechamber.Insertthescrewintothefrontholeandpush

inuntilitbottoms.Screwintothecylindersoatleast4to6threadshaveentered.

Installthewasherandnut.Tightenthenut.Thiscompressesthebrakechamberspring

andreleasestheparkingbrake.
