408MAINTENANCEANDLUBRICATION

COOLINGSYSTEM

CoolantLevelCheck

WARNING

DONOTremovethecaptothesurge

tankwhiletheengineandradiatorare

stillhotandunderpressure.Scalding

uidand/orsteammaybeblownout

underpressureifthecapistakenoff

toosoon.

CAUTION

Addonlypremixedcoolantmade

upof50%cleanwaterand50%

antifreeze.SeetheOperator’sManual

VehicleMaintenanceformoredetailed

information.

Checkcoolantlevelinthecoolanttank.Thetankshouldbefull.Addcoolantas

necessary.

W2006041

1FillCap
