INSTRUMENTSANDCONTROLS63

W3034026

MidLevelCluster

1.Tachometer

2.UpperTell-Tales

3.Speedometer

4.FrontBrakeAirPressure

5.RearBrakeAirPressure

6.OilPressure

7.AftertreatmentDEFTankGauge

8.MalfunctionIndicatorLamp(MIL)

9.DriverInformationDisplay(DID)

10.FuelLevel

11.IntakeManifoldPressure

12.HillStartAssist

13.LowerTell-Tales
