TP 39217202 XC70(08-) & S80(07-) 2012 214
74/30
20-pin black
No. Floor harness Harness driver’s seat
11 73/5004 Branching point
VT-OG
4/52C2:3 Power Seat Module (PSM)
BU-RD
12 73/5003 Branching point
GY-OG
4/52C2:4 Power Seat Module (PSM)
GY-RD
13 31/65 Ground connection, LHD
73/5030 Branching point, LHD
BK-OG
8/51 Front left side airbag igniter
BK
31/67 Ground connection, RHD
73/5029 Branching point, RHD
BK-BU
14 73/5044 Branching point
VT-GN
4/52C2:1 Power Seat Module (PSM),
LHD
4/52C2:6 Power Seat Module (PSM),
RHD
RD-WH
15 11C/13:2 Fuse in distribution box
passenger compartment
GY-RD
4/52C1:1 Power Seat Module (PSM),
LHD
4/52C1:7 Power Seat Module (PSM),
RHD
RD
16 73/5035 Branching point, LHD
73/5023 Branching point, RHD
BK-VT
BK-GN
73/3 Branching point
BK
17 4/9C1:35 Supplemental restraint
system module (SRS)
BU-OG
3/93:1 Contact, driver’s seat belt
buckle
-
18 4/9C1:36 Supplemental restraint
system module (SRS)
VT-BN
3/93:2 Contact, driver’s seat belt
buckle
-
19 -
-
-
-
20 -
-
-
-
74/31
20-pin black
No. Floor harness Harness passenger seat
173/5023Branching point, LHD
73/5035 Branching point, RHD
BK-GN
BK-VT
9/13A:1 Seat Heating Module (SHM),
passenger side
BK
211C/23:2Fuse in distribution box
passenger compartment
WH-OG
9/13A:4 Seat Heating Module (SHM),
passenger side
YE-RD
3-
-
-
-
474/409:16Connector, LHD
74/409:15 Connector, RHD
BN-VT
9/13A:2 Seat Heating Module (SHM),
passenger side
WH-GN
54/9C1:31Supplemental restraint
system module (SRS)
OG
3/256:1 Position sensor passenger seat
USA/CDN
-
64/9C1:32Supplemental restraint
system module (SRS)
BN-YE
3/256:2 Position sensor passenger seat
USA/CDN
-
74/9C1:74Supplemental restraint
system module (SRS), LHD
4/9C1:24 Supplemental restraint
system module (SRS), RHD
OG
8/52:1 Igniter side airbag front right
OG
84/9C1:75Supplemental restraint
system module (SRS), LHD
4/9C1:23 Supplemental restraint
system module (SRS), RHD
BU-OG
8/52:2 Igniter side airbag front right
OG-BU
continues
Connectors
74/30:11-20 - 74/31:1-8
