Volvo XC70 2012 - Connectors

TP 39217202 XC70(08-) & S80(07-) 2012 213
74/9
12-pin black
No. Engine compartment harness Heater harness
1-
-
-
-
2-
-
4/7C1:2 Combustion Preheater Module
(CPM)
YE
311B/10:2Fuses in the engine
compartment fuse box
YE-VT
4/7C1:3 Combustion Preheater Module
(CPM)
RD
473/3034Branching point
BK-RD
4/7C1:4 Combustion Preheater Module
(CPM)
BN
5-
-
-
-
673/3020Branching point
VT-OG
4/7C1:6 Combustion Preheater Module
(CPM)
BK
774/504:41Connector
YE-RD
4/7C1:7 Combustion Preheater Module
(CPM)
BU
8-
-
-
-
96/73:2 Coolant pump
GN-OG
4/7C1:9 Combustion Preheater Module
(CPM)
BN
10 6/73:1 Coolant pump
WH-VT
4/7C1:10 Combustion Preheater Module
(CPM)
RD
11 73/3019 Branching point
GY-OG
4/7C1:11 Combustion Preheater Module
(CPM)
GN
12 -
-
-
-
74/30
20-pin black
No. Floor harness Harness driver’s seat
173/5035Branching point, LHD
73/5023 Branching point, RHD
BK-VT
BK-GN
9/12A:1 Seat Heating Module (SHM),
driver’s side
BK
211C/24:2Fuse, distribution box in
passenger compartment
VT-GN
9/12A:4 Seat Heating Module (SHM),
driver’s side
YE-RD
3-
-
-
-
474/409:15Connector, LHD
74/409:16 Connector, RHD
WH-GN
9/12A:2 Seat Heating Module (SHM),
driver’s side
WH-GN
54/9C1:30Supplemental restraint
system module (SRS)
YE-VT
3/255:1 Position sensor driver’s seat
USA/CDN
-
64/9C1:29Supplemental restraint
system module (SRS)
BU-GY
3/255:2 Position sensor driver’s seat
USA/CDN
-
74/9C1:24Supplemental restraint
system module (SRS), LHD
4/9C1:74 Supplemental restraint
system module (SRS), RHD
OG
8/51:1 Front left side airbag igniter
OG
84/9C1:23Supplemental restraint
system module (SRS), LHD
4/9C1:75 Supplemental restraint
system module (SRS), RHD
GN-OG
8/51:2 Front left side airbag igniter
OG-BU
94/9C1:17Supplemental restraint
system module (SRS)
OG
8/92:1 Lap belt tensioner, driver
-
10 4/9C1:18 Supplemental restraint
system module (SRS)
BN-GN
8/92:2 Lap belt tensioner, driver
-
continues
Connectors
74/9 - 74/30:1-10
