TP 39217202 XC70(08-) & S80(07-) 2012 295
Component illustrations
3/276 - 4/16
3/276 Lock contact, RH rear door
3/281 Infotainment Control Module (ICM)
3/282 Switch indicator 1st gear
3/284 Diagnostic contact, brake light
3/291 Tailgate closing switch, V70
3/293 Handsfree control panel cellular
phone
4/6 Climate Control Module (CCM)
4/7 Combustion Preheater Module (CPM)
4/9 Supplemental restraint system
module (SRS)
4/16 Brake Control Module (BCM)
