Volvo XC70 2012 - Page 36

TP 39217202 XC70(08-) & S80(07-) 2012 36
31/1 Ground connection, PTC
9/42 PTC-element
31/2 LH wheel housing
4/71 Cooling fan control module
6/114 Vacuum pump
8/84 Switch, vacuum pump
9/32 PTC resistor, crankcase ventilation
31/3 Body, battery
1/1 Battery
7/240 Battery monitoring sensor (BMS)
31/4 Engine
31/XX4 Ground connection
31/6 Bottom rail, left
3/26 Switch unit, power driver’s seat, LHD
3/27 Switch unit, power passenger seat, RHD
3/126 Driver Door Module (DDM), LHD
3/127 Passenger Door Module (PDM), RHD
3/128 Left rear door module (LDM)
3/156 Gear Selector Module (GSM), LHD
3/176 Switch, driver’s door power window, LHD
3/273 Lock contact, LH front door
3/275 Lock contact, LH rear door
4/52 Power Seat Module (PSM), LHD
6/36 Lock motor, central locking, LH front door
6/57 Lock motor, central locking, LH rear door
8/134 Solenoid, reverse interlock, manual, LHD
9/1 Front 12V outlet, LHD
9/12 Seat Heating Module (SHM), driver’s side, LHD
9/13 Seat Heating Module (SHM), passenger side, RHD
9/25 Rear 12V outlet, LHD
10/161 Lighting mug holder, LHD
10/286 Lighting floor driver’s side, LHD
10/287 Lighting floor passenger side, LHD
16/45 Navigation system portable, LHD
19/4 Analog clock, LHD
Ground connections
31/1 - 31/6
