6 Operation
5. Attach the pulse oximetry sensor:
Pulse oximetry
sensor
Point of attachment
MCS2-SoftTip
pulse oximetry
sensor
Special feature:
The finger mark
must point
upwards
MCS2-Wrap
pulse oximetry
sensor
Special feature:
The transmitter and
receiver of the
pulse oximetry
sensor must be
aligned to face
each other on one
axis.
