Service Manual FB 7100 Programming
4 - 68 January, 2005
4.3.7 Change comm. route menu
Introduction The Change comm. route menu is used to set the mode of data read-out to
a pc or a hand held terminal. Data can be retrieved via infra-red connection
or via a serial data cable
4.3.7.1 Change comm. route
This table describes the options of the Change comm. route menu.
First, select ‘Closed door’ or ‘Opened door’ depending on the type of data
retrieval device. Secondly, select the communication route.
v Sel Esc^
CHANGE COMM. ROUTE
* Closed door
Opened door
Sub menu Description
Closed door
(key switch
activated)
Serial XModem
For data retrieval via a serial data cable and
XModem protocol.
Serial EDDCMP:
For data retrieval via a serial data cable and
EDDCMP.
IR XModem:
For data retrieval via infra-red connection and
XModem protocol.
IR EDDCMP:
For data retrieval via infra-red connection and
EDDCMP.
Back to terminal:
This option is used to enable communication
between the vending machine and a pc, e.g. to
change the setup of data in the machine.
Opened door
(key switch
deactivated)
Terminal mode:
This option is used to enable communication
between the vending machine and a pc, e.g. to
change the setup of data in the machine.
Configurator mode
For data retrieval via a PSION hand-held terminal
or configurator tool.
