Service Manual FB 7100 Dosing System
5C - 8 January, 2005
C.2.7 Removing the spring for lid from ingredient canister
Preparation Before removing the spring for lid from instant ingredient canisters
• Open the door
• Remove the instant ingredient canister in question, see Operator Man-
ual.
Remember to close the outlet spouts of the instant ingredient canister be-
fore removing it.
Removal of spring
in lid
Follow these steps to remove the spring in canister:
Installation of lid Make sure spring is correctly positioned in lid. Put one hinge tab in its
holder on the canister and let the other hinge tap click in place.
Step Action Illustration
1 Using, for example, the flat
end of small slotted tip screw
driver, flex the hinge tab in
either side of the lid to the
side, and remove the lid. (See
illustration).
2 Remove the spring from the
canister.
