Service Manual FB 7100
January, 2005 5K - 11
K.2.11 Removing the cover for vending machine controller (VMC)
Preparation Before removing the cover for electronic box:
• Disconnect the power supply.
• Open the door
• Remove instant ingredient canisters.
Ensure that the machine is disconnected from the mains electrical supply!
The machine is only isolated from the mains supply when the plug has
been pulled out.
Removal Follow these steps to remove the cover for electronic box:
Installation Installation is done in reverse order.
Step Action
1 Loosen two screws.
2 Lift off the cover plate.
