Service Manual FB 7100 Brewer System
5B - 6 January, 2005
B.3.3 Testing the brewer unit next to the machine
There is an increased risk of injuries. Keep parts of your body and loose
clothing away from the brewer.
Preparation • Switch off the main switch, disconnect the power supply, and close the
water tap.
• Remove the brewer, see this section, page 5B-4.
• Connect a hose to the water inlet elbow tube (1), and put the end of the
tube into a container, so that the water does not run into the machine.
Initiating Test Follow these steps to initiate test of the brewer unit outside the machine.
1
Step Action
1 Plug the adapter
cable harness (1)
between the 15-pole
plug of the brewer
unit and the
connection socket of
the brewer unit in
the machine.
Note: For service
parts refer to the
spare parts list)
2 Reconnect the power supply, switch on the main switch, and open the water
tap.
3 Actuate the safety switch.
1
