Service Manual FB 7100
January, 2005 2 - 3
2 Installation
2.1 Transport / Handling
2.1.1 Dimensions and general transport instructions
Dimensions The following table states the dimensions of the machine
Weight Approx. 50 kg (without ingredients).
General transport
instructions
Observe the following instructions / cautions:
• Transport the machine carefully in its original packaging.
• Only transport the machine in upright position.
• Do not turn the vending machine upside down.
• Do not lift the vending machine from the side.
• Do not lift the vending machine with whatever sling or rope.
• Do not place one packed machine on top of another..
General storing
instructions
• When storing machine, ensure that it is only stored indoors and take
precautions against parasites and frost.
• Keep the machine away from unusual odours.
2.1.2 Transport and storage conditions
General Note To prevent damage to the machine, (un)load and handle the machine with
special care.
It is possible to lift the machine, both with a motor or hand operated fork
lift, placing the forks in the front or rear side of the pallet.
Precautions
before transporta-
tion and storage
Before storing or transporting a used vending machine to a new location
the following steps must be taken
Topic Measurement
Height 870 mm
Width 450 mm
Depth 378 mm (cabinet), 475 mm (cabinet+door)
Step Action
1.
Switch off the main switch and disconnect the power supply plug.
2.
Disconnect the machine from the water supply.
3.
Empty the ingredient canisters.
