Wittenborg FB 7100 - 2.7 Technical Specifications

Service Manual FB 7100
January, 2005 2 - 13
2.7 Technical specifications (total overview)
Dimensions and
Weight
Table of dimensions of machine with or without packing:
Water supply Connect the vending machine to a cold water supply (potable water).
Power consump-
tion
Machine without cold unit 213W
- Heating element: 2000W
- Power consumption: according to EVA-EMS 124,5Wh/l
- Power consumtion at 24 hours of standby:
according to EVA-EMS 2940 Wh
Power Supply Power supply: 230V AC
Fuses:
- Line: 10A
- Neutral: 10A
- Transformer, primary 2A
- Transformer, secondary (on VMC) 8A
Frequency: 50 Hz
Outlet valves (solenoid valves) 24V DC
Inlet valve (solenoid valve) 24V DC
Whipper motors 24V DC
Ingredient motors 12V DC
Description Dimensions with
packing
Dimensions without
packing
Height) 1010 mm 870 mm
Width 670 mm 450 mm
Depth 575 mm 378 mm (Cabinet)
475 mm (Cabinet+door)
Weight 75 kg 64 kg
(without ingredients)
Type of pressure Hot machine, only Hot and cold
machine
Min. back pressure (dynamic) 0.8 bar 1.5 bar
Max. pressure (static) 10 bar 8 bar
