Service Manual FB 7100
2 - 14 January, 2005
Phases Single phase+neutral+earth (IEC-standard)
Brown: Phase
Blue: Neutral
Yellow/green: Earth
The machine must be connected to an earthed electric circuit
which is secured by an extra fuse. The connection to a supply
with an integrated fault current safety switch is recommended.
If missing, it is recommended to install a fault current safety
switch. The connection must be made using an earthed safety
plug socket complying with valid instructions.
Connecting cable Mains cable: Approximately 3500 mm
Temperature Hot water temperature: 95°C-97°C ±1% (203°F-207°F)
Cold water temperature: max. 25°C (77°F)
Requirements Table of requirements to installation and environment
Storing tempera-
ture
-20°C to 36°C (68°F to 97°F)
Ambient tempera-
ture
5°C to 36°C (41°F to 97°F).
Boiler Capacity: 3.5 l
Boil over sensor Triggering temperature: 80°C (176°F)
(Temperature reestablished: 85°C (185°F)).
Boiler tempera-
ture sensor
Adjustable: Recommended value 94°C - 96°C (201°F - 205°F)
Dry boiling protec-
tion
Triggering temperature: 120°C (248°F)
Relative humidity Max. 80% RH (relative humidity) at 36°C (-2/+0) (97°F).
Installation Up to 2000 m above MSL, when using the machine in greater
heights it must be changed over by the service.
Environment The machine may only be used indoors (IP 20).
