Service Manual FB 7100 Brewer System
January, 2005 5B - 3
B.3 (Dis-)assemblies
B.3.1 Safety instructions
Installation and repair works on the machine may only be carried out by
trained service technicians.
General Mounting Instructions
Scraper guide Follow this instruction to assemble the scraper guide:
Support Follow this instruction to assemble the support:
Instruction
•
The guiding lugs (1) have to
point towards the brewer’s
fastening holes (rear side)
and the cable harness (2).
2
1
Instruction
•
The screw. (1) has to be
fastened by means of
Locktite.
1
