Service Manual FB 7100
5D - 2 January, 2005
D.2.2 Removing locking catch for drip guide
Preparation Before removing the locking catch for drip guide
• Open the door
• Switch off the main switch.
Replacement Follow these steps to replace the locking catch:
Installation Installation is done in reverse order.
Step Action Illustration
1 Remove two screws from holder
plate for locking catch
2 Pull out locking catch.
