Wittenborg FB 7100 - Removing the Brewer Housing

Service Manual FB 7100 Brewer System
5B - 8 January, 2005
B.3.5 Removing the brewer housing
Preparation Before removing the brewer housing
• Switch off the main switch, disconnect the power supply, and close the
water tap.
• Remove the brewer, see this section, page 5B-4
• Remove the brewer cylinder, the filter plate holder, and the scraper, see
this section, page 5B-7.
Removal Follow these steps to remove the brewer housing:
Assembly Assembly is done in reverse order.
Note: Consider screws of different lengths!
Step Action
1 Remove the four screws (1).
2 Remove the coffee canister bracket (2).
3 Remove the three screws (3).
4 Remove the brewer housing.
1
3
2
