Wittenborg FB 7100 - Technician Menu Flow

Service Manual FB 7100 Programming
4 - 50 January, 2005
4.3.4 Technician menu flow
This diagram displays the full flow of the Technician menu.
Technician
Adjust system
Calibration
Ingredient
Valve
Cold wate
r
Temperatures
Lower cup senso
r
Cup sensor status
Brewer park pos.
Pot Sensor On/Off
Reset relationship
Change Comm. route
Closed door
Serial XModem
Serial EDDCMP
IR XModem
IR EDDCMP
Back to terminal
Opened door
Terminal Mode
Configurator Mode
Payment settings
Single/Multi vend
Set payment type
Set max credit
Set max change
Obligation to buy
Coin inhibit
Low change inhibit
Audit unit Ext/Int
Exact change eq.
Exact change offset
Keyboard inhibit
Price mode
Revalue
Immediate change
Currency code(auto)
EUR
DKR
GBP
SKR
NOK
Currency code(man)
Coin validato
r
