Service manual FB 7100 Programming
4 - 84 January, 2005
Fan on/off Tests if the fan is running correctly by turning it on for
five seconds.
Test whipper no. x Runs a test of selected whipper for 0.5 seconds.
To perform the test, press ‘Sel’, select whipper no. (no.
1 = left most whipper) and press ‘OK’.
More whippers can be tested subsequently.
Test all whippers Runs a test of all whippers in a sequence from left to
right.
To perform the test, press ‘Sel’. A beep will sound after
the testing of each whipper. Press any button to stop
the test.
Test valve no. x Runs a test of selected valve for 0.5 seconds.
To perform the test, press ‘Sel’, select valve no., and
press ‘OK’.
More valves can be tested subsequently.
Test all IN valves Runs a test of all IN valves in a sequence.
To perform the test, press ‘Sel’. A beep will sound after
the testing of each valve. Press any button to stop the
test.
Test IN motor no. x Runs a test of selected IN motor for two seconds.
To perform the test, press ‘Sel’, select IN motor no. (no.
1 = left most IN motor), and press ‘OK’.
The message “Please remove the IN canisters” now
appears in the display. You may either remove the
canisters or ignore the message and continue the test
by pressing any key.
Note: If you run the test with the canisters still in
the machine, ingredient powder will be dropped
into the mixing funnels, but no water is used in this
test. Therefore, the funnels should be emptied
after the test.
More IN motors can be tested subsequently.
If the test run is not successful, either the general
error message mentioned at the beginning of this
section or the following message will appear in the
display:
Test IN motor no. x
(continued)
• “Ing. motor x overload”
Possible causes:
- Worn motor or gear. See how motor is changed in
chap. 5C, page 5C-8.
- Ingredient canister spout is closed. If you run the
test without removing the ingredient canisters, the
spouts must be open during testing. Open spout(s)
and retry.
Sub menu Description
