Service Manual FB 7100 Brewer System
5B - 22 January, 2005
Assembly Assembly is done in reverse order.
2 Remove the bearing
housing (1) and the spring
(2).
3 Fix the tachodisc by means
of eg. a screwdriver while
unscrewing the nut.
4 Hold the large gear wheel
tightly and remove the nut
(1).
5 Remove the large gear
wheel with toothed belt and
small gear consecutively.
Step Action Illustration
1
2
1
