Service Manual FB 7100
January, 2005 5D - 5
Position Action Illustration
Higher Remove screw no. 1.
This will allow the cup
platform to be set in a
higher position, e.g. for very
small cups.
Lower Remove screw no. 2.
This will allow the cup
platform to be set in a lower
position, e.g. for large mugs.
Locked
position
lower
Move screw no. 1 to the
topmost screw hole.
This will lock the cup
platform in the lower of the
two standard positions.
Locked
position
higher
Move screw no. 2 to the
bottommost screw hole.
This will lock the cup
platform in the higher of the
two standard positions
1
2
